品牌：ALPSALPINE(阿尔卑斯阿尔派)
产品特点：状相同，也可作为脉冲开关（20脉冲）。
按键寿命：1万次、3万次
应用领域：工业设备。
| 产品编号 | 底盘个数 | 电路数 | 接点数 | 切换角度 | 切换时限 | 旋转扭矩 | 操作部形状 | 操作部长度 |
| SRBM120700 | 1 | 2 | 2 | 30±3° | Non shorting | 40±20mN·m | 18-tooth serration | L: 15mm |
| SRBM121300 | 1 | 2 | 2 | 30±3° | Non shorting | 40±20mN·m | Flat | L: 15mm |
| SRBM131300 | 1 | 2 | 3 | 30±3° | Non shorting | 40±20mN·m | 18-tooth serration | L: 15mm |
| SRBM131400 | 1 | 2 | 3 | 30±3° | Non shorting | 40±20mN·m | 18-tooth serration | L: 20mm |
| SRBM140700 | 1 | 2 | 4 | 30±3° | Non shorting | 40±20mN·m | 18-tooth serration | L: 15mm |
| SRBM140800 | 1 | 2 | 4 | 30±3° | Non shorting | 40±20mN·m | 18-tooth serration | L: 20mm |
| SRBM149501 | 1 | 2 | 4 | 30±3° | Non shorting | 40±20mN·m | Flat | L: 20mm |
| SRBM150500 | 1 | 1 | 5 | 30±3° | Non shorting | 40±20mN·m | 18-tooth serration | L: 15mm |
| SRBM154002 | 1 | 1 | 5 | 30±3° | Non shorting | 40±20mN·m | Flat | L: 15mm |
| SRBM160700 | 1 | 1 | 6 | 30±3° | Non shorting | 40±20mN·m | 18-tooth serration | L: 15mm |
| SRBM1L0800 | 1 | 1 | 20-pulses | 18±3° | - | 15±7mN·m | 18-tooth serration | L: 15mm |
| SRBM1L1400 | 1 | 1 | 20-pulses | 18±3° | - | 15±7mN·m | Flat | L: 15mm |
