品牌：ALPSALPINE(阿尔卑斯阿尔派)
产品特点：实现金接点的高可靠性，与IC相同形状可自动插入，对应2~10电路的切换式开关。
按键寿命：3千次
应用领域：白色家电、家庭用分电盘、蓄电池。
| 产品编号 | 焊接方法 | 操作部形状 | 动作力 | 包装状态 | 电路数 |
| SSGM120100 | Insertion | Standard | 3.5±2.5N | Stick | 2 |
| SSGM130100 | Insertion | Standard | 3.5±2.5N | Stick | 3 |
| SSGM140100 | Insertion | Standard | 3.5±2.5N | Stick | 4 |
| SSGM150100 | Insertion | Standard | 3.5±2.5N | Stick | 5 |
| SSGM160100 | Insertion | Standard | 3.5±2.5N | Stick | 6 |
| SSGM170100 | Insertion | Standard | 3.5±2.5N | Stick | 7 |
| SSGM180100 | Insertion | Standard | 3.5±2.5N | Stick | 8 |
| SSGM190100 | Insertion | Standard | 3.5±2.5N | Stick | 9 |
| SSGM1A0100 | Insertion | Standard | 3.5±2.5N | Stick | 10 |
| SSGM240100 | Insertion | Flat | 3.5±2.5N | Stick | 4 |
| SSGM260100 | Insertion | Flat | 3.5±2.5N | Stick | 6 |
| SSGM280100 | Insertion | Flat | 3.5±2.5N | Stick | 8 |
| SSGM2A0100 | Insertion | Flat | 3.5±2.5N | Stick | 10 |
| SSGM640200 | Reflow | Standard | 3.5±2.5N | Taping | 4 |
| SSGM680200 | Reflow | Standard | 3.5±2.5N | Taping | 8 |
| SSGM720101 | Reflow | Flat | 3.5±2.5N | Taping | 2 |
| SSGM740101 | Reflow | Flat | 3.5±2.5N | Taping | 4 |
| SSGM760102 | Reflow | Flat | 3.5±2.5N | Taping | 6 |
| SSGM780103 | Reflow | Flat | 3.5±2.5N | Taping | 8 |
