品牌:ALPSALPINE(阿尔卑斯阿尔派)
产品特点:通过丰富的产品系列,支持各种数字AV机器系列。
动作力:0.35N max.
按键寿命:5万次
应用领域:白色家电、音响、健康器具、汽车导航仪、汽车音响 HVAC等。
产品编号 | 操作方向 | 电路数 | 接点数 | 操作部形状 | 端子形状 | 动作力 |
SPPB110300 | Horizontal | 1 | 1 | Push | For Lead | 0.35N max. |
SPPB120200 | Horizontal | 1 | 1 | Push | For Lead | 0.35N max. |
SPPB310400 | Horizontal | 1 | 1 | Push | For Lead | 0.35N max. |
SPPB320100 | Horizontal | 1 | 1 | Push | For Lead | 0.35N max. |
SPPB1A0100 | Horizontal | 1 | 1 | Actuator A | For Lead | 0.35N max. |
SPPB1A0101 | Horizontal | 1 | 1 | Actuator A | For Lead | 0.35N max. |
SPPB2A0100 | Horizontal | 1 | 1 | Actuator C | For Lead | 0.35N max. |
SPPB2A0101 | Horizontal | 1 | 1 | Actuator C | For Lead | 0.35N max. |
SPPB512300 | Vertical | 1 | 1 | Push | For PC board (Dip) | 0.35N max. |
SPPB610400 | Horizontal | 1 | 1 | Push | For PC board (Dip) | 0.35N max. |
SPPB620300 | Horizontal | 1 | 1 | Push | For PC board (Dip) | 0.35N max. |
SPPB5A0100 | Vertical | 1 | 1 | Actuator A | For PC board (Dip) | 0.35N max. |
SPPB6A0100 | Horizontal | 1 | 1 | Actuator A | For PC board (Dip) | 0.35N max. |
SPPB6A0400 | Horizontal | 1 | 1 | Actuator A | For PC board (Dip) | 0.35N max. |
SPPB530701 | Horizontal | 1 | 1 | Push | For PC board (Reflow) | 0.35N max. |
SPPB530601 | Vertical | 1 | 1 | Push | For PC board (Reflow) | 0.35N max. |
SPPB630101 | Horizontal | 1 | 1 | Push | For PC board (Reflow) | 0.35N max. |
SPPB640201 | Horizontal | 1 | 1 | Push | For PC board (Reflow) | 0.35N max. |
