品牌:ALPSALPINE(阿尔卑斯阿尔派)
按键行程:2mm行程
产品特点:被公认为使用方便的中型通用型。
按键寿命:1万次
应用领域:白色家电。
产品编号 | 行程 | 操作部方向 | 操作部长度 | 电路数 | 接点数 | 动作力 | 安装方法 | 切换时限 | 焊接方法 |
SSSS912000 | 2mm | Vertical | 2mm | 1 | 2 | 3±1.5N | Standard | Non shorting | Manual, Dip |
SSSS910400 | 2mm | Vertical | 2mm | 1 | 2 | 3±1.5N | Snap-in (t1.6) | Non shorting | Manual, Dip |
SSSS919500 | 2mm | Vertical | 2mm | 1 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Standard | Not specified | Manual, Dip |
SSSS918500 | 2mm | Vertical | 2mm | 1 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Snap-in (t1.6) | Not specified | Manual, Dip |
SSSS922000 | 2mm | Vertical | 2mm | 2 | 2 | 3±1.5N | Standard | Non shorting | Manual, Dip |
SSSS921800 | 2mm | Vertical | 2mm | 2 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Standard | Not specified | Manual, Dip |
SSSS912500 | 2mm | Vertical | 4mm | 1 | 2 | 3±1.5N | Standard | Non shorting | Manual, Dip |
SSSS910800 | 2mm | Vertical | 4mm | 1 | 2 | 3±1.5N | Snap-in (t1.6) | Non shorting | Manual, Dip |
SSSS919800 | 2mm | Vertical | 4mm | 1 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Standard | Not specified | Manual, Dip |
SSSS918700 | 2mm | Vertical | 4mm | 1 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Snap-in (t1.6) | Not specified | Manual, Dip |
SSSS922500 | 2mm | Vertical | 4mm | 2 | 2 | 3±1.5N | Standard | Non shorting | Manual, Dip |
SSSS923200 | 2mm | Vertical | 4mm | 2 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Standard | Not specified | Manual, Dip |
SSSS920600 | 2mm | Vertical | 4mm | 2 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Snap-in (t1.6) | Not specified | Manual, Dip |
SSSS916900 | 2mm | Horizontal | 2mm | 1 | 2 | 3±1.5N | Standard | Non shorting | Manual, Dip |
SSSS915001 | 2mm | Horizontal | 2mm | 1 | 2 | 3±1.5N | Snap-in (t1.6) | Non shorting | Manual, Dip |
SSSS91B900 | 2mm | Horizontal | 2mm | 1 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Standard | Not specified | Manual, Dip |
SSSS926400 | 2mm | Horizontal | 2mm | 2 | 2 | 3±1.5N | Standard | Non shorting | Manual, Dip |
SSSS928500 | 2mm | Horizontal | 2mm | 2 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Standard | Not specified | Manual, Dip |
SSSS916400 | 2mm | Horizontal | 4mm | 1 | 2 | 3±1.5N | Standard | Non shorting | Manual, Dip |
SSSS914503 | 2mm | Horizontal | 4mm | 1 | 2 | 3±1.5N | Snap-in (t1.6) | Non shorting | Manual, Dip |
SSSS91B600 | 2mm | Horizontal | 4mm | 1 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Standard | Not specified | Manual, Dip |
SSSS91A601 | 2mm | Horizontal | 4mm | 1 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Snap-in (t1.6) | Not specified | Manual, Dip |
SSSS925800 | 2mm | Horizontal | 4mm | 2 | 2 | 3±1.5N | Standard | Non shorting | Manual, Dip |
SSSS923802 | 2mm | Horizontal | 4mm | 2 | 2 | 3±1.5N | Snap-in (t1.6) | Non shorting | Manual, Dip |
SSSS928200 | 2mm | Horizontal | 4mm | 2 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Standard | Not specified | Manual, Dip |
SSSS925701 | 2mm | Horizontal | 4mm | 2 | 3 | a, c → b 2±1N、b → a, c 3±1.5N | Snap-in (t1.6) | Not specified | Manual, Dip |
