品牌：ALPSALPINE(阿尔卑斯阿尔派)
产品特点：具有两种旋钮形状的立式。
按键寿命：无负载1万次、负载1万次（0.1A 30V DC）
按键行程：1.5mm
应用领域：汽车导航仪 汽车音响 HVAC、画面、音响、专业音响等。
| 产品编号 | 切换时限 | 行程 | 全行程 | 动作力 | 安装方法 | 电路数 | 按键形状 | 动作 | 端子形状 |
| SPPH110800 | Non shorting | 1.5mm | 2.5mm | 2(+1, -0.7)N | PC board | 2 | Standard | Latching | Straight |
| SPPH110300 | Non shorting | 1.5mm | 2.5mm | 2(+1, -0.7)N | PC board | 2 | Standard | Momentary | Straight |
| SPPH120400 | Non shorting | 1.5mm | 2.5mm | 2(+1, -0.7)N | PC board | 2 | Short | Latching | Straight |
| SPPH120100 | Non shorting | 1.5mm | 2.5mm | 2(+1, -0.7)N | PC board | 2 | Short | Momentary | Straight |
| SPPH130400 | Non shorting | 1.5mm | 2.5mm | 2(+1, -0.7)N | PC board | 2 | Standard | Latching | Snap-in |
| SPPH130100 | Non shorting | 1.5mm | 2.5mm | 2(+1, -0.7)N | PC board | 2 | Standard | Momentary | Snap-in |
| SPPH140300 | Non shorting | 1.5mm | 2.5mm | 2(+1, -0.7)N | PC board | 2 | Short | Latching | Snap-in |
| SPPH140100 | Non shorting | 1.5mm | 2.5mm | 2(+1, -0.7)N | PC board | 2 | Short | Momentary | Snap-in |
| SPPH110900 | Non shorting | 1.5mm | 2.5mm | 3(+1, -0.7)N | PC board | 2 | Standard | Latching | Straight |
| SPPH130500 | Non shorting | 1.5mm | 2.5mm | 3(+1, -0.7)N | PC board | 2 | Standard | Latching | Snap-in |
| SPPH140400 | Non shorting | 1.5mm | 2.5mm | 3(+1, -0.7)N | PC board | 2 | Short | Latching | Snap-in |
