品牌：ALPSALPINE(阿尔卑斯阿尔派)
安装方式：卧式
产品特点：可对应多回路的大型卧式。
动作力：2电路 2±1N ，3±1.5N、4电路 2.3±1N，4±2N
按键寿命：1万次、3万次
按键行程：2.5mm
应用领域：音响。
| 产品编号 | 切换时限 | 行程 | 全行程 | 额定 | 动作力 | 安装方法 | 电路数 | 动作 | 端子形状 |
| SPUN191400 | Non shorting | 2.5mm | 3.5mm | Standard | 2±1N | PC board | 2 | Latching | Straight |
| SPUN191600 | Non shorting | 2.5mm | 3.5mm | Standard | 2±1N | PC board | 2 | Latching | Snap-in |
| SPUN190900 | Non shorting | 2.5mm | 3.5mm | Standard | 2±1N | PC board | 2 | Momentary | Straight |
| SPUN191000 | Non shorting | 2.5mm | 3.5mm | Standard | 2±1N | PC board | 2 | Momentary | Snap-in |
| SPUN194700 | Non shorting | 2.5mm | 3.5mm | Standard | 2.5±1N | PC board | 4 | Latching | Straight |
| SPUN194900 | Non shorting | 2.5mm | 3.5mm | Standard | 2.5±1N | PC board | 4 | Latching | Snap-in |
| SPUN192600 | Non shorting | 2.5mm | 3.5mm | Medium-current | 3±1.5N | PC board | 2 | Latching | Straight |
| SPUN192800 | Non shorting | 2.5mm | 3.5mm | Medium-current | 3±1.5N | PC board | 2 | Latching | Snap-in |
| SPUN19C400 | Non shorting | 2.5mm | 3.5mm | Medium-current | 4±2N | PC board | 4 | Latching | Snap-in |
